CPU
CPU
Rockchip RK3568
Frequency
2.00 GHz
Processing units
4 Cores Cortex-A55
TDP
6 W
Memory
Size
2 GB
Type
Onboard DDR4
Storage
Onboard
32 GB, Onboard eMMC
Network
Network Controller
1 x Realtek RTL 8211E Gigabit Ethernet
Ethernet Interface
1 x RJ45
Wi-Fi/BT
Onboard Wi-Fi/BT module
Mobile Network
1 x Full-size Mini-PCIe for 3G/4G
1 x SIM Slot
Display
GPU
ARM Mali-G52
Graphic Engine
OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1
Multi-Media
4K 60fps H.265/H.264/VP9 decoders
1080P 60fps H.265/H.264 encoders
Display Interface
1 x HDMI (Max. 4096 x 2160 @60 Hz)
1 x HDMI (Max. 2560 x 1440 @30 Hz)
I/O interface
USB
1 x USB3.2 Gen1 (OTG), 1 x USB3.2 Gen1
2 x USB2.0
Serial Port
1 x RS232
Audio
1 x 2-IN-1 headset (MIC-IN & AUDIO-OUT)
Button
1 x Power on, 1 x Recovery
Antenna
1 x Connector for Wi-Fi/BT
1 x Connector for 3G/4G (Reserved)
System
Watchdog Timer
NA
Auto Power On
Yes
RTC
Set up independently every day, a week as a cycle
Power Requirement
DC-IN, 12 V/2.08 A
Dimensions
116.6 mm x 107.4 mm x 30 mm (4.59” x 4.23” x 1.18”)
Construction
Metal, Black
Operating System
Android 11
Operating Temperature
0°C ~45°C (32°F~113°F) @0.7m/s Air Flow
Humidity
95% @ 45°C (non-condensing)
Certifications
CE, FCC Class B
