Vantron DE20-BT Industrial DTU
Vantron DE20-BT Industrial DTU is a compact solution for serial communication and Bluetooth 5.0 connectivity tailored to industrial automation. It supports CAT M cellular networks and protocols such as PPP, IP, and TCP/UDP for reliable real-time data transmission.
Featuring a serial port, wide voltage input (5V~36V), and an extended temperature range (-20℃ to +70℃), DE20-BT offers fanless heat dissipation and consumes less than 5W, ensuring efficient operation and lower maintenance requirements.
Commonly used in industrial IoT, energy monitoring, and transportation sectors like power distribution and oil & gas, it supports Modbus and MQTT protocols and is wall-mountable with an IP30 rating for demanding environments.
Key features
- Serial port for communication
- Ultra-low power consumption
- High reliability
- Long service time
- Efficient fanless heat dissipation
- Wide input voltage & temperature range
- Vanity free, easy to deploy
Specifications
- LTE: CAT M
- Bluetooth: BT 5.0, BLE Coded PHY supported
- Serial port: 1 x RS232/485 for data communication1 x RS232 for device configuration
- LED indicator: 1 x 4G LTE status indicator1 x Serial port status indicator1 x Power indicator1 x Error indicator
- Button: 1 x Restore button
- Dimensions: 100mm x 74mm x 34mm (Enclosure only)
- Installation: Wall mounting
- IP rating: IP30
- Input: 5V~36V, 1 x Power connector
- Consumption: < 5W
- Configuration tool: VT Dtool
- Multiple data centers: Supported
- Network protocol: PPP, IP, TCP/UDP
- Southbound protocol: Modbus
- Northbound protocol: MQTT
- Temperature: Operating: -20℃ ~ +70℃ Storage: -40℃ ~ +85℃
- Humidity: Operating: RH 5%-95% (Non-condensing)
- EMC level: EMC Level 2
- Certification: FCC, UL, CE
