ASRock Industrial NUC BOX-320 Fanned BOX PC

The ASRock Industrial NUC BOX-320 is a compact fanned barebone system powered by Intel 3rd Gen Core processors featuring two performance and four efficiency cores. It supports up to 64GB DDR5 6400MHz memory with In-Band ECC, designed for reliable industrial operation.

This system provides dual 2.5 Gigabit LAN ports, dual HDMI 2.1 outputs, and two USB Type-C ports with DisplayPort 1.4a for triple display support. Storage includes two M.2 Key M slots with PCIe Gen4 for high-speed SSDs, alongside Wi-Fi 6E connectivity.

Ideal for industrial automation and edge computing, it supports wide temperature ranges, VESA mounting, Intel PTT TPM, and Windows 10/11 OS for flexible deployment in embedded and IoT systems.

Key Features
Intel® Core Processors Series 3 (Wildcat Lake -U)
1 x 262-pin SO-DIMM DDR5 6400MHz up to 64GB, supports In-Band ECC
2 x USB3.2 Gen2x2, 3 x USB3.2 Gen1, 2 x M.2 Key M, 1 x M.2 Key E
1 x Intel 2.5 Gigabit LAN, 1 x Realtek 2.5 Gigabit LAN
Supports Triple display, 2 x HDMI 2.1, 2 x DP 1.4a (from Type-C)
Intel® PTT
19V/90W Power Adapter
117.5 x 110.0 x 49mm (4.63" x 4.33" x 1.93"), Fanned Barebone

Specifications
Processor System
CPU: Intel® Core Processors Series 3 (Wildcat Lake -U)
CPU: Core™ 5 320, 2P+4LPE
CPU: *Support In-Band ECC
Chipset: MCP
BIOS: AMI SPI 256 Mbit
Memory
Technology: Single Channel DDR5 6400 MHz
Capacity: 64GB
Socket: 1 x 262-pin SO-DIMM
Graphics
Controller: Intel® Graphics
HDMI: HDMI 2.1
HDMI: Max resolution up to 4096x2160@60Hz
DisplayPort: DisplayPort 2.1/ 1.4a, DP++
DisplayPort: Max resolution up to 4096x2160@60Hz
MultiDisplay: Max 3 display (Included 2 outputs from Type-C)
Expansion Slot
M.2/WLAN: 1 x Wi-Fi 6E 802.11ax + BT 5.3 (M.2 Key E, 2230 PCIe x1, USB 2.0 for Wireless)
Audio
Interface: Realtek ALC256, High Definition Audio.
Ethernet
Controller/ Speed: LAN1: Intel® I226V with 10/100/1000/2500 Mbps
Controller/ Speed: LAN2: Realtek RTL8125BG with 10/100/1000/2500 Mbps
Connector: 2 x RJ-45
Front I/O
USB: 1 x USB 3.2 Gen1 (Type-A)
USB: 2 x USB3.2 Gen2x2 (Type-C, 5V/3A, Supports DP1.4a display output)
Audio: 1 (headphone & microphone jack)
Rear I/O
HDMI: 2 x HDMI 2.1
Ethernet: 2 x 2.5 Gigabit LAN
USB: 2 x USB 3.2 Gen2 (Type-A)
DC Jack: 1
Storage
M.2: 1 x M.2 (KEY M, 2242) with PCIe Gen4 x1 for SSD
M.2: 1 x M.2 (KEY M, 2242/2280) with PCIe Gen4 x2 for SSD
RAID: **supported by identical interface (PCIe)
RAID: PCIe interface: 2*M.2 Key M
Watchdog Timer
Output: From Super I/O to drag RESETCON#
Interval: 256 Segments, 0, 1, 2, ...255sec
Power Requirements
Input PWR: 12V~24V DC-In Jack
Power On: AT/ATX Supported
Power On: - AT : Directly PWR on as power input ready
Power On: - ATX : Press button to PWR on after power input ready
Environment
Operating Temp: 0ºC ~ 40ºC
Storage Temp: -40° C ~ 85° C
Operating Humidity: 5% ~ 90% (non-condensing)
Storage Humidity: 5% ~ 90% (non-condensing)
Mechanical
Mounting: VESA mount
Dimensions (L x W x H): 117.5 x 110.0 x 49mm (4.63" x 4.33" x 1.93")
Weight: Net Weight:1.0Kg
Others
OS Support: Windows 10/11
TPM: Intel® PTT
Certifications: CE, FCC
