Innodisk AXMB-D150 Mini-ITX Industrial Motherboard

The Innodisk AXMB-D150 Mini-ITX Industrial Motherboard features an Intel Core Ultra 7 Processor 265H delivering up to 97 TOPS for AI computing across CPU, GPU, and NPU. It includes 16GB DDR5 6400 MT/s memory, a 512GB PCIe Gen 4 x4 M.2 SSD, and an 8MP MIPI over Type-C camera.

It offers HDMI 2.1, DisplayPort outputs, dual 2.5GbE LAN, USB4, multiple USB 3.2 ports, three M.2 slots, PCIe Gen 5 expansion, SATA connections, and configurable serial ports. Internal I/O and security features support demanding system integrations.

Typical applications include industrial automation, edge AI, and smart city deployments requiring reliable, scalable computing and security within 0°C to 60°C environments.

Order Information
AXMB-D150-A01: Intel CPU: Core Ultra 7 265H; COM: 4; LAN: 2; USB: 1 x USB4, 4 x USB 3.2 Gen 2x1, 2 x USB 2.0; Display: HDMI 2.1, DP++ 2.0, DP++ 1.4, DPoC (DP 2.1); M.2: 3 (B+M+E); Operating Temp.: 0°C~60°C; Power Cord: -A01 (EU cord)
AXMB-D150-A02: Intel CPU: Core Ultra 7 265H; COM: 4; LAN: 2; USB: 1 x USB4, 4 x USB 3.2 Gen 2x1, 2 x USB 2.0; Display: HDMI 2.1, DP++ 2.0, DP++ 1.4, DPoC (DP 2.1); M.2: 3 (B+M+E); Operating Temp.: 0°C~60°C; Power Cord: -A02 (US cord)
AXMB-D150-A03: Intel CPU: Core Ultra 7 265H; COM: 4; LAN: 2; USB: 1 x USB4, 4 x USB 3.2 Gen 2x1, 2 x USB 2.0; Display: HDMI 2.1, DP++ 2.0, DP++ 1.4, DPoC (DP 2.1); M.2: 3 (B+M+E); Operating Temp.: 0°C~60°C; Power Cord: -A03 (CN cord)
AXMB-D150-A04: Intel CPU: Core Ultra 7 265H; COM: 4; LAN: 2; USB: 1 x USB4, 4 x USB 3.2 Gen 2x1, 2 x USB 2.0; Display: HDMI 2.1, DP++ 2.0, DP++ 1.4, DPoC (DP 2.1); M.2: 3 (B+M+E); Operating Temp.: 0°C~60°C; Power Cord: -A04 (JP cord)
AXMB-D150-A05: Intel CPU: Core Ultra 7 265H; COM: 4; LAN: 2; USB: 1 x USB4, 4 x USB 3.2 Gen 2x1, 2 x USB 2.0; Display: HDMI 2.1, DP++ 2.0, DP++ 1.4, DPoC (DP 2.1); M.2: 3 (B+M+E); Operating Temp.: 0°C~60°C; Power Cord: -A05 (UK cord)

Key Features
Features Intel Core Ultra 7 Processor 265H, delivering 97 TOPS for edge AI computing
Equipped with Intel Core Ultra Series 2 platform-certified components
Mini-ITX form factor (170 x 170mm)

Specifications
Platform
Intel CPU: Core Ultra 7 Processor 265H
Cores (P+E+LPE): 16C (6P + 8E + 2LPE)
Threads: 16
Max. Frequency: 5.3GHz
Cache: 24MB
CPU TDP: 28W
BIOS: Insyde SPI 256Mbit
AI Accelerator
AI Engine: Intel AI Boost up to 97 TOPS via (CPU+GPU+NPU)
Memory
Technology/Socket: DDR5 6400MT/s, 2 x 262pin DDR5 CSODIMM
Max. Capacity: 64GB (up to 32GB per slot) (2 x 8GB, total 16GB pre-installed)
Graphics
Controller: Intel Arc 140T GPU
Graphic Engine: Hardware Decode: 8K60 12b HEVC/VP9/SCC, 8K30 10b AV1, 5K60 10b HEVC/VP9/SCC, 4K60 8b AVC; Hardware Encode: 8K30/5K60 8/10b HEVC/VP9/SCC, 4K60 10b HEVC/VP9/SCC, 4K60 8b AVC
Displays
HDMI 2.1 (8K@60Hz): 1
DP++ 2.0 (8K@60Hz): 1
DP++ 1.4 (4K@60Hz): 1
DPoC (DP 2.1) (8K@60Hz): 1
Ethernet
LAN (Intel I226 2.5Gbps): 2
Expansion Slots
M.2 2242/3052 B Key: 1 x (PCIe Gen 4 x1/USB 3.0), with Nano SIM socket
M.2 2280 M Key: 1 x (PCIe Gen 4 x4); 512GB M.2 SSD pre-installed
M.2 2230 E Key: 1 x (PCIe Gen 4 x1/USB 2.0/CNVi)
PCIe x8: 1 x (PCIe Gen 5)
External I/O
USB4 (40Gbps): 1 (Thunderbolt 4 support PD 15W 5V@3A)
USB 3.2 Gen 2x1 (10Gbps): 4
Audio (Realtek ALC897): 1 x Mic-in, 1 x Line-out
HDMI-In (micro-HDMI): 1
Internal I/O
SATA: 2 x 2.5" SATA III SSD/HDD
COM1: RS232/422/485
COM2: RS232/422/485
COM3: RS232/422/485
COM4: RS232/422/485
MIPI over Type-C: 2 (x4 Lane); 1 x MIPI over Type-C cameras pre-installed
USB 2.0: 2
Power
Power Input Voltage: DC 12V
Power Connector Type: DC DIN 4pin; ATX 8-pin
Environment
Operating Temperature: 0°C~60°C
Storage Temperature: -40°C~85°C
Operating Humidity: 90% at 40°C Relative humidity, non-condensing
Watchdog Timer
Interval: Programmable from 1 to 255 Seconds
Security
TPM 2.0: dTPM2.0 (Hardware, Infineon:SLM9670AQ2.0)
Physical Characteristics
Dimension L x W (mm): 170 x 170
Net Weight/Gross Weight (KG): 0.4 KG/1.4KG
Operating System
Microsoft Windows 11 IoT Enterprise 2021 LTSC
Regulation
Safety: CE/FCC Compliance
